fig. 13 draw H.L., B.L. and L.D., and find LMP,take B 2 to left and A 4 to left of B, also S 4 to right ofB. Erect AC and BD perpendiculars to AB, and each 4 inheight; join CD, C C.Y, D C.Y., B C.Y., and S LMP. LetS LMP cut B C. Y. in G; draw GF parallel to BD, and FE3 26 DRAWING. parallel to CD :… … THE LINE. 27 Exercise III. (H = 6^ L.D. = 4^ scale Y = IO 1. Draw a line 4 in length on G.P., parallel to P.P. and 4within it, directly in front. 2. Draw a line 4 in length parallel to G.P. and 4 above it,touching P.P. 4: to left, and perpendicular to it. 3. Draw a line 3 in length perpendicular to…
