Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)

McGuirl, Thomas H. [from old catalog] · Toronto, W. Briggs; · leaf 80

An illustration from Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates, 1887, leaf 80 — plained;then draw the hexagons, one on G.P., the other 4 above it;then join similar angles in each, forming the required hexagon.(Fig. 43.) THE CYLINDER. 75 TThe C^rlinder. The drawing of the cylinder differs from that of the prism,only in the plan. Draw the circles, forming the ends, in theproper… … Fig. 44. 76 DRAWING. Example 2.—Draw a cylinder lying on G.P., 4 to right,having end perpendicular to P.P., and touching it; cylinder8 long and 3 in diameter.

Geometrical drawing · Perspective
