The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1897)
Auchincloss, William Stuart, 1842-1928 · New York : Van Nostrand · leaf 102
ns must be affixed, their adaptabilitytested and modified by circum-stances, and finally all must be —. unfolded and developed in per-fect harmony. When the sub-ject of scheming the link motioncomes in order, we find that pe-culiarities of detail have already fixed the ratio of the crank arm to the… … link no. gibly presented when the mind is able to follow their ope-ration in the solution of a practical example, we will takefor illustration of our method the following dimensions : ao Ratio of crank to connecting rod=l : 7AEccentric circle diameter=5J inches.Maximum cut-oft=0.92 stroke.Rocker…
Steam-engines
