The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 146
sitions Nos. 9 and 10 * If the ratio of crank to connecting rod had been that of 1 : 5 or 6, the linesc2 c8, c3 c3 would have had a greater inclination to the central line of motion,thereby removing h and h3 to h4 and hh, and depressing the shaft to some im-practicable point T2, where it would have… … Liu.- ,,C M
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
