The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 210
ng with those who hold such monop-olies, and who alone can make use of them, the onus ofexplaining their principles and advertising their points ofexcellence. APPENDIX. FORMULAE EELATING TO CEANK ANDPISTON MOTIONS. CRANK ANGLE EQUATIONS. Upon comparing the positions assumed by a piston under the… … the piston is advanced beyond its normal position by a distance ef equalto the ver. sine of the angle a included between the connecting rod andcentre line of the engine. On the return stroke it will be found in arrearby the same distance. The object of this investigation is to determine formulas…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
