Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 265
Voltmeter VoltmeterSwitch -SeriesParallelSwitches BatterySwitch … HHHHHHHf-IHHHHHH Fig. 209 generator capacity can be reduced, the battery being chargedwhen the load on the plant is light and discharged in parallelwith the generators when the load exceeds^ the capacity ofthe generators. The shaded portion of the curve in Fig. 210represents what is called the peak…
Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
