The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing. (1857)

Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Johnson, William, 1823-1864 · New York : Stringer & Townsend · leaf 202

An illustration from The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing., 1857, leaf 202 — . • Fig. 30. an uneven outline. In the instrument represented in figs. 29 and30, the parts which traverse the guide-grooves in the plate, q, con-sist of small steel wheels, o, p, carried in the forked ends of the * See page 17. steel spindles, o, p, which are entered loose into the socket legs,0,… … Fig-. 32. tion with regard to the grooves, whatever be the position of the bar,K, and pen, s. In adjusting the instrument, it is simply necessaryto set the pen and centre legs, so that the distance of the twolatter from the former shall coiTespond respectively with thesemi-transverse and…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
