other slide traverses the cosine, a b. To apply this practically,any two of the slides, actuated by g, h, and i, are connected bythe proportionate wheels, whilst the third gives the cutting mo- tion in the remaining direction of the cube. To reverse theangle, a subsidiary wheel is introduced into…
