The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing (1854)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Cory, William Johnson, 1823-1892 · New York, Stringer & Townsend · leaf 274
onding to the pitchof the guide-screw; l, grooved shaft, in connection with the dif- BOOK OP INDUSTRIAL DESIGN. 175 ferential or barrelling motion, which is attached to the verticalslide, and consists of a segmental screw-wheel, embracing a motionof about G0°, gearing with a tangent-screw on the… … bearings of the screw, which slide in dovetails, and consequentlythe vertical slide, being thus affected by the eccentricity of thecrank-pin. The shafts, a, h, and I, and screws, G and k, are con-nected by a system of wheels, the arrangement of which is clearlyshown in the end view, fig. 2; but g,…
Decorative arts · Drawing
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
