Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 105
bearing 26. It should be noted that the section through thevalve chamber taken on cylinder No. 2 is at a point consider-ably back from the center line of the cylinders and not in thesame plane as the section shown on cylinder No. 3, which istaken through the center line of the cylinders. In the… … Fig. 19. Cross-Section Through Typical Four Cylinder AutomobileEngine. Courtesy of the Chicago Technical College. GAS, OIL AND STEAM ENGINES 101 water leaves the cylinder and passes to the radiator. At thelower end of the stroke is the piston, one-half of which isshown in section and one-half in…
