that scale. The inlet valve C and exhaust valveG are shown in position. The latter is worked through a leverH and side rod J by an eccentric K driven from the crank-shaft L by spur gearing. When the speed exceeds the normal,a centrifugal governor pushes down a steel piece N, whichengages with a… … C 5b a u=. -h O 0 Oh Q 1 o bDO,4 +3 o «2 COCO 6 M ft 232 THE INTERNAL COMBUSTION ENGINE [chap, vin cylinder during the charging stroke of the piston because thereis free communication with the atmosphere through the ex-haust valve, and consequently no charge of oil and air canbe drawn into the…
