Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 107
Fig. 19-a. Buda Four Cylinder Automobile Motor. Carburetor Side. … Fig. 19-b. Buda Motor, Purnp Side, Cylinders En Bloc.,: GAS, OIL AND STEAM ENGINES 103 In this motor both the inlet and exhaust valves are locatedon the same side of the cylinder which arrangement classifiesthe engine as an L type, the extended valve pockets forming anL with the center line of the…
