g. 25. A hollow steelcolumn is bolted to the top of the cylinder and protrudes fromthe water jacket, which is fastened to it with the usual shrunk GAS, GIL AND STEAM ENGINES 113 ring. To this column rs attached a hollow T shaped pipe ofphosphor bronze, the column of the T piece forming the out-let… … Fig. 25. End Elevation of A. B. C. Motor. A small bracket projecting from the T piece forms a saddleon which the valve spring rests. This is a plain semi-ellipticalleaf spring which works both valves. It is slotted at each endand slightly turned up so as to engage with a cotter pin passedthrough a…
