Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 152
entpistons, and the two outer pistons connected respectively. Infact the second cylinder pistons are duplicates of those justshown and are connected to the linkage in such a manner asto have the corresponding pistons in one cylinder act withthe corresponding pistons in the second. (34) Koerting Two… … Fig. F-ll. Koerting Two Stroke Cycle Engine with Scavenging andCharging Cylinders. as it is of the double acting type, it will serve to illustrate thecycle of that class of engine equipped with independent airpumps. Several of these engines are in use in Europe thathave an output of over 4,000…
Internal combustion engines · Traction-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
