Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 315
g shaft driven by the engine. Whenthese weights are rotated rapidly the bottoms are thrown out-wardly by the centrifugal force and tend to assume a horizontalposition. The faster the weights are rotated, the greater willbe the tendency for the bottoms of the weights to come intothe horizontal, and… … Fig. 124-d. Governor and Governor Mechanism of Fairbanks-MorseType R E Engine. . The Fly-Balls, Springs, and Control Rods AreShown on the Governor Staff. The Upper End of the Bell CrankGoes to the Throttle. with the speed of rotation and consequently with the speed ofthe engine. The exact relation…
Internal combustion engines · Traction-engines
