Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 351
ting on the inner run of the fly-wheel.The motion of the engine is transmitted to an intermediatereversing device through bevel gears, this being necessary forthe reason that the crank-shaft runs fore and aft, or parallel 316 GAS, OIL AND STEAM ENGINES to the length of the tractor. A double acting… … Big Four, Four Cjlinder Tractor Motor. is transmitted to the master gears on the bull wheels. Thedifferential shaft is in one piece.The main driving wheels are very large when compared with
Internal combustion engines · Traction-engines
