Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 372
Fig. H. Lassoe-Lovelsin Burner. which the steam or air issues. As would be expected, theatomization is not as perfect with this burner as with theatomizer or injector type. A burner in which the oil and steam mix before passing outinto the furnace through the final opening is known as a Cham- … Sheedy Oil Burner, Used for Locomotives. ber burner, and is shown by Fig. D. In some respects, atleast in construction, it is similar to the injector burner, butit does not possess the lifting abilities of the latter becauseof the open space in front of the stea^m nozzle. The atomiza- 368 GAS, OIL…
Internal combustion engines · Traction-engines
