Fig. 27.—McCord Lubricator Section Through One Pump. 106 McCORD LUBRICATOR downward, the oil is forced past the ball checks K and L,through the delivery pipe M, into the terminal check N,where the gravity valve O is lifted and the oil forcedthrough delivery passage R. 312. The feed is adjusted by… … Fig. 28.—Transformer For McCord Lubricator. adjustment of the nut Q, which allows a greater or lessamount of sliding of the cross-head P on the pump plungerE. 313. Any individual pump may be operated by hand atany time, and one or more bearings can thus be given an THE TRANSFORMER 107 extra amount…
