Practical instructor and reference book for locomotive firemen and engineers: a practical treatise .. (1911)
Lockhart, Charles F. (Charles Fulton), b. 1872 · New York, The Norman W. Henley publishing co. · leaf 90
Fig. 12.—Simplex Injector, Sectional View. steam directly against the solid water in the combiningchamber. Other authorities hold the more generallyaccepted theory that the water is forced into the boilerby the velocity of the steam in passing through the injectorfrom the boiler and the induced… … 88 INJECTORS
Locomotives
