Practical mechanical drawing and machine design self taught .. (1907)

Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 126

An illustration from Practical mechanical drawing and machine design self taught .., 1907, leaf 126 — ure a more efficient circulation of the water. The uptake is connected to the crown of the fire-box and to the crown of the outside shell byflanged joints as shown in Fig. 205, or by weldedangle iron rings which are riveted to the crownsand to the uptake. The part of the uptake which passes through… … Fig. 205—Vertical Cross Tube Boiler. 124 MECHANICAL DRAWING for the same purpose. The cast-iron liner may fitclose into the uptake, or it may be separated from

Mechanical drawing · Machine design

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
