Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 33
Fig. 65. … greater than the length of one part, describe arcscutting each other as A-2, C-2, B-3, D-3, etc., alsoB-1, D-5. Describe the end arcs A-1, E-5 with a radius equal to B-2. Lines joining A-1, B-2, C-3,D-4 and E-5 will all be radial.To inscribe any regular polygon in a circle— Fig. 66. Divide the…
Mechanical drawing · Machine design
