Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 39
l-ig- 57- Draw any convenient lineFG; join A^FandAC. Drawany line HK parallel to FG.At H draw the line HLparallel to FA, and at Kdraw the line KL parallel toGA, cutting each other at L.Draw a line through L andA ; AU is the convergentline required. Circles. 32. To find the centre of acircle. Draw… … Fig- 59- 26 GEOMETRICAL DRAWING AND DESIGN. 33.
Geometrical drawing · Design · Drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
