Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 43
cause the area of the sheet or disc ofmetal required for raising a hemisphere must be 40 MECHANICAL DRAWING equal in area to the combined areas of two discs,each equal tO the diameter of the hemisphere. To find the cubic contents of a hemisphere—Fig. 99. Multiply the cube of the diameter by.2618.… … ring add the inner diameter of the ring, multiplythe sum by the square of the cross-sectional diam-eter of the ring and by 2.4674, the product is thecubic contents. To find the superficial area of a cylindrical ring.To the cross-sectional diameter of the ring add theinner diameter of the ring.…
Mechanical drawing · Machine design
