Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 95
Fig. 176—Details of Surface Gauge. one of these views a few of the principal dimen-sions are marked. The details, fully dimensioned,are shown separately in Figs. 172 and 173, Explain clearly how the center is moved back-wards and forwards, and also how the spindle con- 92 MECHANICAL DRAWING taining… … Fig. 177—Jack Screw. also the detail of the locking arrangement shownin Fig. 172.Example 17. Surface Gauge. First draw, full A
