Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 212

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 212
VIII FUNDAMENTAL RULES OF PROJECTION 197 … at right angles to the auxiliary plane, or either hinge may be unfastenedfor the purpose of rabatment. Theorems 1 and 2 apply to any object, conceived as anassemblage of points. They may be put in the form ofrules. Thus suppose the plan and elevation on xy to havebeen drawn ; then Rule 1. — To…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
