Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 232

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 232
-y b£ … 218 PRACTICAL SOLID GEOMETRY chap. 185. Problem.—Having given the projections of a cube,and the traces vth of a vertical plane, to determine theplan, elevation, and true shape of the section. The horizontal trace lit is an edge view of the plane, andthe required plan of the section is therefore in…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
