Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 310

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 310
Examples.—1. Draw the plan of a square, .2 side, the plane of which is inclined at 500, one side being inclined at 35°.2. Draw the plan of a square ABCD, 2 side, when the line joiningA to the middle point of BC is inclined at 350 and the plane ofthe square at 500, the point A being on the ground.…
