es theelevation. 185. To project a regular hexagonal prism 7V long, and with sides2^ wide, standing on its base on the H.P., with one face in-clined to the v.P.at an angle of 45. ^ c ^ g*Its nearest edge tobe l| from v.P.Scale \ full size.Fig. 258 A. Draw the line XY,and if below it markthe… … Fig. 258. This completes the elevation. 186. To project the same prism, l3ring with one face on H.P.; itslonger edges to be inclined to the V.P. at an angle of 30°; itsnearest corner to be l\ from v.P. Scale |^ full size. Fig. 258 B, Fix the point/ i j below XY. Draw the line f^, y\ long,at an…
