Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 408

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 408
of acylinder. In each case determine the plan and elevation ofthe curve of intersection of the two surfaces, when the cylinderis turned with its axis parallel to the vertical plane. 2. In Ex. 1 describe a semicircle on xy with centre c and radius2# ; this is the end elevation of a semi-cylinder ;… … 394 PRACTICAL SOLID GEOMETRY chap. 319. Problem. —To determine the projections of theline of intersection of a given cylinder and cone, the axesof which are both vertical. Horizontal section planes are convenient. Consider a plane whose elevation is tin. With centrev and radius // describe a…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
