Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 490

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 490
a square ; join A to one corner P of this square,and meeting BC in R. In the corresponding side be obtain r such thatbr:rc = BR:RC. Join ar and produce to p such thatar : rp = AR: RF. Join bp and draw cq, pq parallel to bp, be. Then beqp is the plan of the square attached to BC\ thetriangle ABC and…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
