Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 76

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 76
62 K … 62 PRACTICAL PLANE GEOMETRY chap. 64. Problem.—To describe a circle which shall passthrough two given points P and Q, and touch a givencircle, centre G. Join PQ, and draw NK bisecting PQ at right angles. Select any point C on NK such that the circle, with C as centreand CQ as radius, will intersect…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
