ack endof the boiler or over the bridge wall. You cannot see thewhole of the boiler head, as it is bricked in from 2 to 3inches above the tubes*. This brick-work is put in to protectthe end of the boiler at the steam-space. The boiler has a 16 PRACTICAL STATIONARY ENGINEERING cast-iron front to… … Figure 5. BOILERS 17 What are tubes made of? Boiler tubes are made of steel or wrought iron, most com-monly of charcoal iron, and lap welded. In the formation ofthe lap the plate is upset, then bent around until the thick-ened edges lap sufficiently. It is then heated successively,about eight…
