A practical treatise on weaving and designing of textile fabrics : with chapters on the principles of construction of the loom, calculations, and colour (1885)

Ashenhurst, Thos. R. (Thomas R.) · Huddersfield, [Eng.] : J. Broadbent · leaf 82

An illustration from A practical treatise on weaving and designing of textile fabrics : with chapters on the principles of construction of the loom, calculations, and colour, 1885, leaf 82
74 WEAVING AND DESIGNING a circle. 'P'rom these arcs the healds are hung, being con- nected with each other below by means of pulleys. In Fig. 13 I have separated this motion from the rest of the loom, so as to show more effectually the connection and working of this part. The treadles c are simply… … %. 13. with the rod at the other end. This rod simply communi- cates the motion to the heald g by means of the lever e f, and the connection of the healds with each other at the bottom is so arranged that as one goes up the other is drawn down, and vice versa. The lines h i shows the warp separated…

Looms · Weaving · Textile fabrics · Textile design

Internet Archive · Getty Research Institute · Public domain (published before 1931). Free to use for anything.
