A practical treatise on coach-building, historical and descriptive : containing full information on the various trades and processes involved, with hints on the proper keeping of carriages, &c. (1881)

Burgess, James W · London : Crosby Lockwood and Co. · leaf 105

An illustration from A practical treatise on coach-building, historical and descriptive : containing full information on the various trades and processes involved, with hints on the proper keeping of carriages, &c., 1881, leaf 105
bolted where the front-staycrosses the puncheons, the other end extending to the front,forming the outside of the socket for receiving the shafts.o c represents a piece of hickory bolted between the two stays.The following dimensions applicable to the figure may beuseful:—Springs lh inches thick,… … Fig. 29. WHEEL-PLATES AND FORE-CARRIAGES. 95
