A practical treatise on weaving by hand and power looms : intended as a text book for manufacturers by hand and power looms, and power loom engineers and especially designed to forward the extension of machinery to all kinds of plain weaving (1846)

White, George, -1724 · Glasgow : J. Niven · leaf 132

An illustration from A practical treatise on weaving by hand and power looms : intended as a text book for manufacturers by hand and power looms, and power loom engineers and especially designed to forward the extension of machinery to all kinds of plain weaving, 1846, leaf 132
120 PRACTICAL TREATISE 203. Fig. 43rd is a transverse section of this con- struction of loom, which is called the Crank ; and as H … Fig. 43. Section of Moving Parts of the Crank Power Loom, without the Frame. it has superseded the Wiper, and is almost the only one in use, it is the one with which we have espe- cially to deal in the further consideration of power loom weaving, o, d\ e\ f, refer respectively to the sword of the…

Weaving · Looms
