Beale, Oscar James, Brown & Sharpe Manufacturing Company (Providence, R.I.) · Providence, R.I. : Brown & Sharpe Mfg. Co. · leaf 48
In these last lines place leg of dividers, and drawfaces and flanks of teeth as in sketch. 6. The radius c d of rack-tooth faces is the samelength as radius c d oi rack-tooth flanks, and is thestraight distance from c to tooth-thickness point h onopposite side of line O A. 7. The radius for fillet… … Fis- T^4 Racks of the same pitch, to mesh with interchange-able gears, should be alike when placed side by side,and fit each other when placed together as in Fig. 14. In Fig. 13, a few teeth of a 15-tooth wheel are shownin mesh with the rack. 30 BROWN & SHAEPE MFG. CO. CHAPTER VIII.…
Gearing
