Pig. 46 … 48 PRACTICAL BULE8 PIPES. To describe a T Pipe at Right angles. Let ABCD, fig. 47, be the length and diameter of the T ; de-scribe the semi-circle CED; divide the semicircle into any num-ber of equal parts; from the points draw lines parallel to AC, as I, 2, 3, &c.; then set off the line ABC,…
