AFig. 21. Examples of Boxing up. Fig. 21 shows a better method than Fig. 22 of rebatingthe boards together. In Fig. 21, the boards B passstraight up from top to bottom, and A A lie withinthem. In Fig. 22 the edges of A A come out to thefaces of B B. This is objectionable, because when A Aswell with…
