Fig. 267. Si Fx /i fgF^ … vij Fig. 268.—The vector difference between the two currents h and h, eachequal to I, is Ii = s/sl. Fig. 267, and the current I2 lags Ix by 120 degrees then the result-ant current It is the vector sum of h and I2 and may be deter-mined as shown in diagram C. If, however, the second coil is…
