Generator2200 Volt <j>| Step upTransformers / Oil Switch … 13,200 Voltsto Substations Power House Terminal Station Fig. 404.—Diagrammatic representation of a high voltage transmission system. transformers while the step-down transformers are placed in aterminal station. The load is carried by several units operatingin parallel so that one machine may be…
