The principles and progress of printing machinery (1900)
Southward, John, 1840-1902, Wilson, Frederick John Farlow. Account of modern printed machine · London : E. Menken · leaf 43
its transit backward and forward ; for theink-table is made to form part of the type-table of themachine. The ink thus deposited by the vibrating roller isdistributed evenly over the entire surface of the inkingtable by means of other rollers placed diagonally across theframe of the machine. These… … Fig. 10.—Inking Arrangements : A, Ductor-roller ; b, Vibrator ; c, Ink-table ; D, Wavers orDistributors ; E, Inking-rollers ; f, Form ; g, Roller Forks. called the * roller forks. As the ink-table moves to andfro under the distributing rollers, they not only rotate, buthave a motion in the…
