Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 57
supporting the cornice on theplate; the roof sheathing and covering; the con-struction of the gutter, with all materials named;the ceiling joists and method of support on theoutside wall; the lath and plaster; the wallsheathing and siding or shingles; the picturemould; the detail of the inside… … 228 o t- i: lU o
Architectural drawing · Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
