Radford's brick houses and how to build them : a standard collection of new, original, and artistic designs for brick houses, apartments, stores and flats, garages, etc. ; together with complete instruction in the manufacture of brick and its practical uses as a building material selected and compiled by William A. Radford ... Every plan designed and executed by a corps of licensed architects of the highest professional standing, assisted by a staff of expert draftsmen. Over 300 designs and details. (1912)
Radford, William A., 1865- · The Radford Architectural Company, Chicago, Ill. and New York, N.Y. · leaf 106
RELIEVINC HRXH RELIEVING F1RCH Fig. 103. Segmental Arches in Brick Walls. A better way is shown. Instead ofmaking the span of the relieving archequal to the opening between the jambsbelow, the arch springs from a pointover the extreme end of the wooden lin- Of course, for such arches, no elab-orate… … Fig 104. Segmental Arch, and How to Lay It Out. tel. In case of fire occurring and thelintel being entirely consumed, the archwould be unaffected, and would con-tinue to carry the weight above.Building inspectors and managersshould insist on the adoption of this the centering. The arch is then…
Brick houses -- Designs and plans · Architecture, Domestic -- United States -- Designs and plans · Trade catalogs -- Architecture, Domestic -- Designs and plans
