with its axis parallel toboth V and H. At the left, A is the profile viewof the cone and cylinder, showing the right-hand end of the latter. This view A shows therelative position of the cone and cylinder, andwould be drawn first if the figures were to bedrawn from given data. The distance X-y, for… … 115 116 MECHANICAL DRAFTING will consist of a single closed curve. If, how-ever, the cylinder were smaller and shown inend \aew entirely within the cone, then therewould be two separate curves. As the cylinder is shown endwise in thisprofile view, the method of solution will be todraw lines or…
