-b are shown in theirtrue lengths, but also all lines parallel to theplane of o-a and o-b. On account of this property, an oblique pro-jection is often more easily made than an iso-metric—as, for instance, in the case of circlesor curves which lie in a plane parallel to the MECHANICAL DRAFTING 139…
