Moulding in ObliqueProjection. Fig. 95. Square Post Partly-Cut Away on Frontand Sides. 127. Two pieces of joist with the ends cutfor halving together, are shown in Fig. 94. Allof the edges are either parallel or perpendicularto the plane of the front face, and are thereforeshown true length. 128.…
