The American house-carpenter; a treatise on the art of building, and the strength of materials (1873)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 399
ence toanother, is, that when shadows are properly made upon the draw-ing by it, the depth of every recess is more readily known, sincethe breadth of shadow and the depth of the recess will be equal. To distinguish between the terms shade and shadow, it will beunderstood that all such parts of a… … 501.— To find the line of shadow on mouldings and other ho-rizontally straight projections.. Fig. 336, 337, 338, and 339,lepresent various mouldings in elevation, returned at the left, inthe usual manner of mitreing around a projection. A mere in-spection of the figures is sufficient to see how the…
Carpentry · Architecture
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
