Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 264
de the same way.Show the tyi3e of windows you expect to use;show the correct profile or outline of the cornice;the general design of the front door and theporch and steps; indicate the glass in the door,whether double strength, plate, or beveled-plateglass. In short, make this front elevation… … ARCHITECTURAL DRAFTING 225 up to the next floor above; but this is not to berecommended, as it detracts from the general ap-pearance of the elevation, and there are otherand better methods of indicating stairs, as ex-plained later. Very often there will be a small section of thehouse on the same…
Architecture · Building
