Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 193
studswith square ends, and spike to sill and girt. Thebeams are shown let into the sill. Fig. 45 illustrates tee halving, as in the case ofwall plates coming together at right angles. Fig. 46 illustrates beveled halving. This jointis used in splicing plates and sills. Fig. 47 illustrates dovetailed…
