you want the scaffold.Set end on ground, and drive stake in solid 299 300 PEACTICAL CARPENTRY ground. A strij) is nailed to the bracket and tothe sheathing to prevent side slipping. Another scaffolding arrangement is shownin Fig. 257. It has much to recommend it, andappears to be superior to the… … PlamFig. 257. A Good Scaffolding Arrangement. It will be seen from the sketch, that twohorizontal pieces instead of one are used, thusX^roviding against lateral movement, without theaid of tlie diagonal strips that are nailed to the PKACTICAL CAllPENTHY 301 uprights and which are always more or…
